C1003 Millwork Channel 19.1mm x 8mm

C1003 Millwork Channel 19.1mm x 8mm

C1003 Millwork LED Integration System Low-Profile Architectural Millwork Channel for Narrow Cove and Downlight Integration The C1003 operates as a low-profile fixture assembly architecture engineered specifically for tight architectural spaces. It establishes a compact mechanical load path within millwork, and it acts as an essential thermal management platform. The channel connects flexible LED tape directly to custom cabinetry or narrow architectural coves. This integration node protects the internal electrical infrastructure from physical damage. It ensures strict dimensional control, and it allows seamless lighting integration without disrupting the surrounding woodcraft or architectural materials. Engineering Function The system regulates LED junction temperatures through optimized passive heat dissipation. The 6063-T5 aluminum structure extracts heat away from the LED engine, and it prevents thermal failure in confined spaces. The channel receives controlled diffusion lenses or Fusion Optix systems. This optical integration ensures smooth light distribution, and it eliminates visual artifacts in shallow downlight applications. Material and Finish Base Material: Low-profile 6063-T5 aluminum structure Standard Finish: Clear Anodized Optional Finishes: White or Black powder coat End Caps: Available in Grey or Black or White System Compatibility LED Engines: Validated for LEDmate LUMAflex and CHROMAflex and VITAflex tape series Optical Control: Compatible with standard diffusion lenses and Fusion Optix systems Connection Interface: Accepts standard LEDmate end caps for millwork integration Installation and Workflow Advantages Fits easily into narrow coves and shallow millwork channels Protects the LED engine from physical damage in high-touch architectural areas Simplifies procurement with standard field cuttable lengths Ensures repeatable installation geometry across complex custom cabinetry Application Environments Custom architectural millwork Narrow ceiling coves Shallow recessed downlighting Under cabinet display lighting Technical Specifications Specification Details Primary Function Mechanical housing and Dimensions Dimension Specification Overall Width 19.10 mm Overall Height 8.00 mm Form Factor Low-Profile Narrow Format Specification and Integration Support This millwork integration system is specified for custom architectural projects requiring strict dimensional tolerances and reliable thermal control in confined spaces. It is engineered for use by custom millworkers and architectural lighting specifiers and OEM lighting manufacturers. ⇩ Download C1003 1-Page PDF Data Sheet

Designer’s Note

Verify compatibility and structural clearances prior to installation.

Specifications
